Alpine®
Fire-Storm®
Windstorm
Resistant Fire Door
 Crossbred
Fire & Storm Protection- High Quality Door at a
Competitive Price
- Certificate up to 20'x30'
- Built in Accordance with Requirements
Specified by Underwriter's Laboratories
Inc.
- Dade County Approved for High
Windloads, up to 187 MPH
|
Available
Classifications:
3 and 4 Hour Approved for Doors in Dividing Fire Walls with Openings not Exceeding
152 sq. ft. in area. • 1.5 Hour Approved for Doors, in Vertical Shaft Openings
not Exceeding 152 sq. ft. in area. • .75 Hour Approved for Doors in Corridor
or Room-Partition Opening not Exceeding 152 sq. ft. in area. • 1.5 Hour
Approved for Doors in Exterior Wall Opening not Exceeding 152 sq. ft. in area. |
The
Fire-Storm® is a combination of the
features of Alpine's Redi-Storm® and Fire-Tite®
models. It is Dade County Approved
for high windloads (up to 187 mph)
as well as UL and MEA approved for
fire protection. It comes in galvanized or stainless
steel and in
a variety of different finishes.
Fire-Storm® curtains are constructed of 2
3/4" flat
steel slats, and can be finished with
powder coating or baked enamel finishes.
Each door is equipped with a 22 gage
steel hood formed to fit the contour
of the end brackets and durable ductile
iron windlock with 1/4" semi-solid
rivets. Our door supports
and brackets are all steel plates no
less than 1/4" thick.
Alpine's Torsion Counterbalance Assembly
is state of the art, providing maximum
security and ease of use.
Click
Here for UL Labeled Smoke and Draft Control Assemblies
Contact
us today to find out which Alpine® solution
is right for you! |
| Fire
Test |
 |
|
|
See for yourself
how Alpine® Fire
Doors handle the
heat. Click
here for some
pictures from one
of our recent fire
tests.
|
|
|
|
|
| |
|
| Powder
Coating |
|
|
 Our
large selection of colors
make our doors decorative
and durable.
|
| Standard
Colors |
| View | Download |
| Special
Effects |
| View | Download |
|
|
|
2 3/4" Flat Slat
|
|
|
Double
Angle Bottom Bar
|
|
|
Structural Guides
with Windbar
|
|
