Insulated Rolling Doors with Metal Backing.- Increased Thermal Protection, Fully Weatherstripped.
- R-Value of 8.25
- 15/16″ Thick Polystyrene
- Optional Polyurethane Insulation
Energy costs are continually on the rise. To help combat the problem as well as provide better protection against the elements, Alpine offers our IMB insulated rolling door design. The IMB-V8® insulated door is a rolling door designed specifically to provide energy efficiency, utilizing a heat resistant polystyrene insulation with a low thermal transmittance factor.
The metal on metal insulated slat has polystyrene insulation that is a minimum of 15/16 ” thick. Slats are available in 22, 20, 18, and 16 gauge steel with a backing of 24, 22, or 20 gauge steel and also available in B.S. Aluminum. Polystyrene slat insulation offers maximum thermal protection. Insulated rolling doors can be push-up, hand-crank, hand-chain or motor operated. All operators can be adapted to specific conditions.
APPLICATION USE
Insulated, Loading Dock Doors.
BOTTOM BARS
Brass, Copper, Galvanized, Aluminum, Stainless Steel, Hot Rolled Steel, Powder Coated, Weather Strip, Brush/Smoke Seal, Pneumatic Edge, Electric Edge, Wireless Edge, Double Angle, Tubular, Extruded “T”, Slope Bar, Curb Closure Plate, Special Cut-Out, Slide Lock.
BRACKET PLATES
Brass, Copper, Hot Rolled A36, Stainless Steel, Galvanized, Powder Coated, Stop Lock Bearing, Internal Charge, Charge Wheel, Motor Prep., Chain Gearing, Thru-Wall Drop Plate, Round Bracket, Square Bracket, Hex Bracket, Single Gear Reducer, Double Gear Reducer.
COUNTERBALANCE ASSEMBLY
Hot Rolled A36, Galvanized, Stainless Steel, Torsion Spring, Life Cycle 17.5 to 400M, Welded Tabs, Taped Holes, Redi-Tube Motor, Thru-Shaft Push-up, Inside Charge, Lock Shaft Collar, Keyed, Bolted.
CURTAIN OPTIONS
Brass, Copper, Galvanized, Stainless Steel, Aluminum, Galvalume, Prime Painted Galvanized, Powder Coated, Mail Slot, Vision Lite, Stamped Endlock, Cast Endlocks, Windlock Option, Brass Endlock, Teflon Endlock, Pass Door.
GUIDE MATERIAL
Brass, Copper, Hot Rolled A36, Stainless Steel, Aluminum, Galvanized Steel, Powder Coated, Structural Angles, Roll Formed Angles, Weather Stripping, Brush/Smoke Seal, Chain Lock Box, Electric Interlock, Heat Tracing, Teflon Lining, Tube Mounting, Pack Out Angle, Flat Plate Mount.
HOOD/COVER
Brass, Copper, Galvanized, Stainless Steel, Aluminum, Galvalume, Prime Painted, Powder Coated, Hood Baffle, Lintel Seal, Smoke Lintel Seal, Back Fascia, Tension Cover, Operator Cover, Round, Square, Hex, Side End Cap, Motor Cover, T.O.C. Cover, F.O.C. Cover, F.O.W. Cover.
MATERIAL STYLE
24 Gauge, 22 Gauge, 20 Gauge, 18 Gauge, Polystyrene Board, Polyurethane Foam.
OPERATION OF DOOR
Chain, Motor, Hand Crank, Redi-Master, Redi-Lift, Chain Gear Reducer, Euro-Drive.
