Alpine® Insul-Sound® Industrial Doors

Quality Sound Resistant Doors

  • Specially constructed industrial doors for sound insulation

    Sound Resistant Doors, Industrial Doors, Sound Resistant Shutters

  • Made with hard, weather resistant plastic backing
  • Request a quote on Quality industrial doors
  • R-Value of 8.0
  • For use in sound stages and recording studios
  • Internal hood baffle prevents weather infiltration through header
  • Available for custom windload designs
  • Torsion spring counterbalance assembly

Alpine introduces the Insul-Sound® sound absorber, noise reducer, and sound barrier rolling shutters. These sound resistant doors and high speed doors have new slats that provide for a full thermal break between the inside and outside of the slat. The back of these industrial doors is made of hard, weather resistant PVC. The inside of these sound resistant shutters provide a full sound barrier for thermal protection. The front slat is available in 22, 20, and 18 gauge steel or B.S. Aluminum with a variety of finishes. Click here to see the High Performance Industrial doors.

Sound Resistant Doors, Industrial Doors, Sound Resistant Shutters

Alpine’s patented Insul-Sound® rolling shutters design allows for the manufacturing of coiling sound resistant doors that are unmatched in the industry.

Alpine Insul-Sound® sound resistant doors and curtains consist of 2 3/4″ flat slats, snap on roll formed from galvanized, optional stainless steel, or aluminum in gauges from 22 gauge to 18 gauge with a noise reduction, sound barrier snap on PVC and insulated core backing. Industrial doors can be push-up, hand-crank, hand-chain or motor operated. All of the operators can be adapted to specific conditions for these high speed doors and folding doors. Locking units can be provided depending on the type of door operation.

APPLICATION USE
Acoustical Doors, Sound Absorber, Quiet Doors, Soundproof, Noise Reduction, Sound Barrier, Soundproof Doors, Sound Protection, Sound Resistant Shutters, Warehouse Facilities, Storage Buildings, Music Recording Studios.

BOTTOM BARS
High Speed Doors and folding doors can have Bottom Bars that are Brass, Copper, Galvanized, Aluminum, Stainless Steel, Hot Rolled Steel, Powder Coated, Weather Strip, Brush/Smoke Seal, Pneumatic Edge, Electric Edge, Wireless Edge, Double Angle, Slide Lock.

BRACKET PLATES
Bracket Plates for Industrial Doors and Rolling Shutters can be Brass, Copper, Hot Rolled A36, Stainless Steel, Galvanized, Powder Coated, Stop Lock Bearing, Internal Charge, Charge Wheel, Motor Prep., Chain Gearing, Thru-Wall Drop Plate, Round Bracket, Square Bracket, Hex Bracket, Single Gear Reducer, Double Gear Reducer.

COUNTERBALANCE ASSEMBLY
Sound Resistant Shutters and Folding Doors can be Hot Rolled A36, Galvanized, Stainless Steel, Torsion Spring, Life Cycle 17.5 to 400M, Welded Tabs, Taped Holes, Redi-Tube Motor, Thru-Shaft Push-up, Inside Charge, Lock Shaft Collar, Keyed, Bolted.

CURTAIN OPTIONS
Curtains for Sound Resistant Doors can be Brass, Copper, Galvanized, Stainless Steel, Aluminum, Galvalume, Prime Painted Galvanized, Powder Coated, Stamped Endlock, Cast Endlocks, Windlock Option, Brass Endlock, Teflon Endlock.

GUIDE MATERIAL
Folding Doors can have Guide Material that is Brass, Copper, Hot Rolled A36, Stainless Steel, Aluminum, Galvanized Steel, Powder Coated, Structural Angles, Roll Formed Angles, Weather Stripping, Brush/Smoke Seal, Chain Lock Box, Electric Interlock, Heat Tracing, Sound Brake, Teflon Lining, Tube Mounting, Pack Out Angle, Flat Plate Mount.

HOOD/COVER
High Speed Doors and Industrial Doors have hoods/covers that may be Brass, Copper, Galvanized, Stainless Steel, Aluminum, Galvalume, Prime Painted, Powder Coated, Hood Baffle, Lintel Seal, Smoke Lintel Seal, Back Fascia, Tension Cover, Operator Cover, Round, Square, Hex, Side End Cap, Motor Cover, T.O.C. Cover, F.O.C. Cover, F.O.W. Cover.

MATERIAL STYLE
22 Gauge, 20 Gauge, 18 Gauge, Polystyrene Board.

OPERATION OF DOOR
Sound Resistant Shutters and Rolling Shutters can be Acoustical doors can be, Chain, Motor, Hand Crank, Redi-Master, Redi-Lift, Chain Gear Reducer, Euro-Drive.

Powder Coating

Our large selection of colors make our doors decorative and durable.

Standard Colors

View | Download

Special Effects

View | Download

Sound Resistant Doors, Industrial Doors, Sound Resistant Shutters

IPB-S Insulated Snap on Slat



Sound Resistant Doors, Industrial Doors, Sound Resistant Shutters

Double Angle with Rubber Astragal



Sound Resistant Doors, Industrial Doors, Sound Resistant Shutters

Structural Guide with Weather Strip





Contact us today to find out which Alpine® solution is right for you!
