Studies have revealed that smoke kills more
often than fire. Fortunately now, Alpine
OverHead Doors, Inc. have developed their
Smoke-Fire-Tite/Smoke-Fire-Shut products
to give people another chance to escape a
fire without the loss of life. Smoke-Fire-Tite
adds proven smoke and draft control to Fire
Doors and Counter Fire Doors. They are designed
to prevent the disastrous spread of smoke
during a fire emergency event, thereby protecting
both lives and severe property damage. Use
at any opening where life safety is a number
one priority, especially interior corridors
and smoke barrier openings.
When selecting a smoke containment product,
it is best to specify a UL labeled
product for you can rest assured that their
performance
and quality has been tested and validated
by an independent third party agency.
Smoke-Fire-Tite products are UL labeled for
fire protection
and meet these specifications required
by insurance and building codes for Smoke
and
Draft control.
- Tested per UL 1784,
the procedure for smoke and draft
control assemblies.
- UL, “S” leakage
rated assembly labeled for smoke
and draft control.
- Meets the requirements
of NFPA 105.
- Meets the requirements
of the International Building Code,
2000, Section 714.2.3.
- UL labeled
for fire protection: 4, 3, 1 ½,
1 and ¾ hour labels
are available for fire doors and
insulated fire doors. 3, 1 ½, 1
and ¾ hour
labels available for counter fire doors.
Smoke-Fire-Tite
Benefits:
- Saves Lives, buildings
and property.
- Controlling the
smoke limits the property damage.
- Air flow and drafts serve to fuel a
fire. Smoke-Fire-Tite
Units help to control and contain
fires by limiting
The flow of oxygen.
- Meets today’s more stringent building
code
Requirements.
- Full product line
offering counter fire doors,
Fire doors, and insulated fire
doors.
Other
Available Features and Benefits
- Redi-Reset
Motor, Redi-Reset Chain, or Redi-Reset
Crank automatic closing systems provide
safe and
Convenient operation. Spring tension
resetting is
Never required and automatic closing
speed is
Safely controlled not to exceed
9” per
second.
- Smoke-Fire-Tite units are
approved for mounting in fire rated
walls for both face of wall or
between jamb mounting conditions.
- Units
are available with curtain
finishes of your choice which include
galvanized, stainless steel, pre-painted or a broad selection
of powder coated finish colors.
- Each unit is built in accordance with
your exact size requirements
and specifications. See back of sheet for size limits listed
by product category.
- Alpine’s 2 year
warranty standard on motor operator’s.
Smoke Fire-Tite Doors
Provides wall opening access and
protects separated areas from the spread
of smoke and fire. These products are suitable
for use in commercial, industrial and institutional
applications.
Sizes: Openings up to 56’ wide by 26’ high
or a maximum of 1200 square feet.
Labeling: In addition
to UL, “S” Label:
- UL Labeled for fire protection; 4, 3,
1 ½,
1 and ¾ hour labels
available.
- Factory Mutual Fire Protection
Approval.
Mounting: Between jambs
or face of wall configurations
for both exterior
and interior walls. Approved wall types for mounting
include structural steel jambs
or
masonry.
Smoke Fire-Tite IMB Doors
Offers the combined benefits of an
insulated door and a UL labeled
fire door product. Provides smoke control
in addition
to UL rated fire protection, sound
attenuation, security and environmental
separation.
Sizes: Openings
up to 56’ wide by 26’ high.
Labeling: In
addition to the UL “S” Label;
- UL labeled for fire protection; 4, 3,
1 ½ , 1 and ¾ hour labels
available.
Mounting: Between
jambs or face of wall configurations
for both exterior
or interior walls. Approved wall
types for mounting
include structural steel jambs
or masonry.
Sound Transmission
Class: S T C 27.
Climate Control: Fire-Tite’s
full perimeter seals and insulated
curtain yields
a 4.2 R value. Used at the exterior
or interior
openings to control varying temperatures
on each side of the door.
Smoke Fire-Storm
Doors (Miami Dade County
Florida Approved)
These doors are designed to withstand
the full range of specific wind load requirements.
Specified wind load designs have been performance
validated in a private testing facility.
Sizes: Openings up to 20’ wide by
30’ high.
Labeling: UL labeled for fire protection; 4, 3, 1 ½ , 1 and ¾ hour
labels
Available.
Mounting: Between jambs or face of wall configurations for both exterior or
interior walls. Approved wall types for mounting include structural steel jambs
or masonry.
Performance Criteria:
- ANSI/DASMA-108.
- ASTM E 330.
- Miami-Dade County test protocols
PA-201, PA-202 and PA-203..
- Florida
Building Code (FBC)
Smoke
Fire-Storm IMB
Doors (Miami
Dade County
Florida Approved)
Offers the combined benefits of an
insulated door and a UL labeled fire
door product. Provides smoke control in addition
to UL rated fire protection, sound
attenuation,
security and environmental separation.
Sizes: Openings up to 20’ wide by 30’ high.
Labeling: In addition
to the UL “S” Label;
- UL labeled
for fire protection; 4, 3, 1 ½ ,
1 and ¾ hour labels
available.
Mounting: Between
jambs or face of wall configurations
for both exterior
or interior walls. Approved wall
types for mounting
include structural steel jambs
or
masonry.
Sound Transmission
Class: S T C 27.
Climate Control: Fire-Storm’s
full perimeter seals and insulated
curtain
yields a 4.2 R value. Used at the
exterior or interior
openings to control varying temperatures
on each side of the door.
Smoke
Fire-Shut Doors
Protects the counter openings
against the spread of smoke and fire,
and can be
used regularly for security purposes.
When the compact components of Smoke
Fire-Shut
Doors are desired, these units
can fully close to the floor.
Sizes: Openings up to 16’ wide when
the height is 7’6” or less. Openings
up to 12’ wide when the height is 10’ or
less.
Labeling: In addition
to UL “S" Label:
- UL labeled for fire
protection; 3, 1 ½, 1 and ¾ hour
labels available.
Mounting: Between
jambs or face of wall configurations
for both exterior
or interior walls. Approved wall
types for mounting
include structural steel jambs,
drywall or masonry. Smoke Split-Integral Frame Fire-Shut Doors
Protects the counter openings against
the spread of smoke and fire, and can be
used regularly for security purposes. When
the compact components of Smoke Fire-Shut
Doors are desired, these units can fully
close to the floor.
Sizes: Openings up to 10’10” wide
when the height is 7’6” or less.
Openings up to 12’ wide when the height
is 10’ or less.
Labeling: In
addition to UL “S" Label:
- UL labeled
for fire protection; 1 ½,
1 and ¾ hour labels available.
Mounting: Between jambs or face of wall
configurations for both exterior
or interior walls. Approved wall
types for mounting
include structural steel jambs,
drywall or masonry. Smoke H-0 Series Marine Bulkhead Fire Door
Sizes: Openings up to 10’ wide when
the height is 8’ or less.
Labels: UL 4, 3,
1 ½ or ¾ hour
label for fire, ULC 2 hour label
for fire and UL “HO” label for
HO Bulkheads.
H-0 Model doors will
not bear an hourly rating.
Mounting: Between jambs or face
of wall configurations for both exterior
or
interior walls. Approved wall types
for mounting include structural steel jambs,
drywall or
masonry.
Fire Control Options
All Smoke Fire-Tite products are
required to be signaled to close
by local smoke detectors or a central
alarm system.
Redi-Reset Motor Operated units
tie directly into the alarm system. All
other units
require a release device for
the alarm system interface.
- Release Devices – Fail-safe
electromechanical devices
that initiate automatic
closing in response to an
alarm signal or following
a ten second power outage.
Battery back-up versions last
up to 72
hours without initiating
a release due to a power
failure.
- Announcers – Safety
devices that provide a visual
and/or
audible advanced warning
when the fire door is about
to close. Can be activated upon
receiving an alarm signal
or a loss of commercial power
when supported by a battery
back-up
device.
- UL 1 ½ Hour
Labeled Countertops for
Counter Shutter Fire
Doors – Steel
or stainless steel countertops
are available
in 14 gauge, #4 finish. Stainless
steel countertops are custom
designed to a maximum
wall opening
width of 11’2” for face of
wall units; 11’10” for between
jambs, for a maximum 24” wall thickness.
Optional Finishes
- For Fire Doors
and Insulated Fire Doors
the curtain and hoods can
be provided with a Power Coated finish whereby you can
select from over 200 colors
for added durability and value.
- Hot-Dip
galvanizing of steel
components is available.
- Full
Stainless Steel of curtains,
guides, tracks and hoods.
- Zinc Rich Gray corrosion
resistant powder coating
also available.
Alpine
OverHead Doors,
Inc.
Emergency
Response Products
Fire-Tite
Doors
Protect and prevent the
spread of fire by automatic
fire door closing in the
event of fire detection with governed
speed
control. Fire doors are designed
for daily use to provide
security, prevent fire
related
human injuries, and gain easy access
or exit from buildings.
Additional Benefits:
- Comply
with Insurance and Building
code requirements.
- The compact overhead
storage of curtain
is ideal for industrial, commercial
and institutional applications.
Sizes: Standard construction
for openings up to 34’ wide,
30’ high
or 1200 sq. feet. Consult factory
for larger door sizes.
Labels: UL 4, 3, 1 ½, 1 or ¾ hour
Labels. Factory Mutual Approved.
Practical Design
Applications: Fire
wall openings in:
- Hospitals
and Health Care Facilities.
- Schools
- Museums
- Hotels
- Warehouses
- High Rise Construction
- Not for
use in openings that are
designed for a means
of egress.
Fire-Tite IMB Doors
Provides UL rated fire protection
plus the security, sound attenuation
and environmental separation. Reduces costs
by meeting multiple design needs,
with
continued energy savings generated
by Fire-Tite’s
IMB sealing and insulation.
Additional
Benefits:
- Sound Transmission Class
: STC 27; Muffles unwanted sound
between areas.
- Climate Control : Insulated
Curtain
yields a 4.2 R-value that can be
combined with full perimeter seals.
Sizes: Openings up to 34’ wide by
22’ high. Consult factory for larger
door sizes.
Labels: UL 4, 3, 1 ½, 1 or ¾ hors
Labels.
Practical Design Applications:
- All
fire wall openings where the
door is to be closed regularly
and sound attenuation needs to be present.
- Exterior openings that require a
fire rating due to the proximity
of other structures or combustible materials.
- Buildings designed for future
expansion where current exterior
wall openings
are to become interior fire wall openings.
- Interior fire wall openings where
the door will be normally closed
to control varying climatic conditions between two areas.
Smoke Fire - Shut UL Labeled Smoke and
Draft Control Assemblies
Designed to limit the spread of fire
and smoke in a fire emergency whereby
protecting human life and property. Equipped
with UL
listed and tested perimeter smoke
seals that are UL labeled for proven smoke
and draft
control per UL 1784. These units
carry two labels, one for fire protection
and one for
smoke and draft control. Insulated
Smoke Fire-Shut units also provide climate
control
with a curtain that yields a 4.2
R-value, plus sound attenuation with a Sound
Transmission
Class STC 27.
Additional Benefits:
- Meets the requirements of NFPA 105
and also the International Building
Code, 2000, Section 714.2.3.
- Increases protection for building
occupants, capital and contents.
- Control’s
smoke thereby limiting property
damage.
- Increases safety and decreases
personal injuries.
Smoke Fire-Tite
Doors
- Sizes: Openings
up to 56’ wide
by 26’ high or a maximum of 1200
sq. feet.
- Labels: UL
4, 3, 1 1/2, 1 or ¾ hour
label for fire and UL “S” label
for smoke and draft control.
Smoke
Fire-Tite IMB Doors
- Sizes: Openings
up to 56’ wide by
26’ high or 1200 sq. feet.
- Labels: UL
4, 3, 1 1/2, 1 or ¾ hour
label for fire and UL “S” label
for smoke and draft control.
Smoke
Fire-Shut Counter Fire Doors
- Sizes: For
openings up to 16’ wide
when the height is 7’ 6” or
less. For openings up to
12’ wide
when the height is 10” or less.
- Labels: UL 3, 1 ½, 1 or ¾ hour
label for fire and UL “S” label
for smoke and draft control.
Smoke
H-0 Series Marine Bulkhead
Fire Door
- Sizes: Openings
up to 10’ wide when
the height is 8’ or less.
- Labels: UL
4, 3, 1 ½ or ¾ hour
label for fire, ULC 2 hour
label for fire and UL “H0” label
for H0 Bulkheads.
- H-0 Model
doors will not bear an
hourly rating.
Practical
Design Applications:
- Buildings
with large occupancy rates.
- Buildings
with significant material inventories.
- Buildings where controlling smoke
and fire increases
the probability of areas remaining unaffected by fire.
- Smoke Fire-Shut: Openings
that will be regularly closed
where there is a need for sound attenuation or climate control
between two areas,
and buildings designed for future expansion where the current exterior
wall openings are
to become interior fire wall openings,
especially with significant
material inventories.
Alpine OverHead Doors, Inc.
Emergency Response
Products
Counter Fire-Shut Doors
Also specified as fire shutters,
these fire doors secure openings above counters
and other similar finished openings on interior
and exterior walls.
Additional Benefits:
- Complies
with Insurance and Building code
requirements.
- Are designed with smaller,
more aesthetically pleasing guides,
slats, brackets
and hood than a fire door.
Sizes: Openings up to 16’ wide when
the height is 7’6” or less;
up to 12’ wide when the height is
10’ or
less.
Labels: UL 3, 1 ½, 1 or ¾ hour
Labels.
Practical Design Applications:
- Smaller
openings in fire rated walls,
especially above counters.
- Openings to
the floor where smaller
components are desired.
Counter
Fire-Shut Doors with Integral
Frames, Retrofit Split Frame Doors
Manufactured and designed at the
factory for a seamless, custom
appearance without requiring assembly in
the
field. Built-in mounted units wrap
around the wall
and are installed while the wall
is being constructed. Slip-in units
are set into finished
walls.
Additional Benefits:
- Fully
assembled prior to pick-up or delivery
to the project site.
Ready for placement into the
wall opening.
- A custom looking finished
product
with high quality design.
Sizes: Openings up to 10’10” wide
by 6’4” high in walls 4 ½” to
24” thick.
Labels: UL
1 ½, 1 or ¾ hour
Labels.
Practical
Design Applications:
- Service window
openings for fire walls in :
- Cafeterias
- Health Care Facilities
- Schools
and Universities
Egress Grille Emergency Grille
Designed to provide the needs of
both security and safety in public
areas or locations. The Egress
Grille allows for
the security of a locked, rolling
grille but immediately responds
in an emergency situation to open the door
allowing
personnel
an easy escape from the building.
Provides separation control in
addition to allowing
an alternate means of egress in an
emergency situation. A Concealed
AutoLock mechanism prevents the
forced opening of a closed grille,
but will not interfere with the
normal access to egress
during an emergency situation.
Additional Benefits:
- Fail-safe emergency response
capability.
- No manual locking
or unlocking required.
- No resetting
is necessary to resume a normal
operation.
Sizes: Openings
from 5’ to 24’ wide
and 4’ to 20’ high.
Practical Design
Applications:
- Corridor protection
in any public building that
has limited functional
space at varying time intervals and also for special
events, such as in :
- Schools
- Hospitals
- Office Buildings
- Transportation
Terminals
- Separation control
applications where emergency
personnel will
require immediate access to secured areas during a crisis or
emergency incident.
- Applications
where the combined ease of opening
and security is desired.
|
